Off-Grid Inverter |
|
Product name : Off-Grid Inverter |
Item : Off-Grid Inverter |
Off-Grid Inverter:
Off-grid inverter is a special inverter that specialized in supporting solar and wind power system. It has the following characteristics:
1.High transfor efficiency, highest can reach to 95%.
2.Output ture sine wave
3.Protection function completely, output short-circuit protection( take load short-circuit), overload protaction, DC overload or under-voltage protection.
4.Strong ability of resist concussion, can loading all kinds of electric apparatus and industry equipments. Such as: air condition, refrigerator, television, fan, washer, fill water electric motor, tortile gate, and etc.
5.The service life is long, can reach a decade.
specification
|
capacity
|
NS/NW
|
200W
|
300W
|
500W
|
1KW
|
2KW
|
3KW
|
5KW
|
10KW
|
20KW
|
30KW
|
50KW
|
100KW
|
DC
|
24V/12V
|
24V/12V
|
24V
|
48V
|
120V
|
240V
|
240V
|
240V
|
360V
|
360V
|
492V
|
492V
|
THD
|
≤3%
|
Dc to AC transfer efficency
|
80%--95%
|
O/P wave form
|
Sine wave
|
O/P VOLTAGE
|
220V±3%,or 120v±1%
|
380v±3% ,or208v±1%
|
O/P frequency
|
50HZ/60HZ
|
50HZ/60HZ
|
Protections
|
Protection against short-circuit, overload,over-heating, high or low voltage
|
Unit Size (MM)
|
372*122*195
|
397*145*215
|
900*575*1330
|
800*1000*2200
|
N.W(KG)
|
5.6
|
6.9
|
7.8
|
10.5
|
25
|
32
|
60
|
80
|
120
|
170
|
272
|
389
|
|
